3500 Lb Power Tongue Jack, Heavy Duty Electric Trailer Jack, 12V DC, 23.15 Lb

Features Attach the jack using three bolts (grade 5, 3/8”-16 UNC bolts with washers and nuts or 3/8”-16 plate as shown in Fig . mounting plate to ensure direct metal to metal contact. Bolts should be tightened to 15-20 ft-lb. If a lower support plate is not already present, install one in the bottom of the trailer frame. Maximum Lift Capacity: 3500 lbs (continuous use) Retracted Height:30” Vertical Travel: 18” Power Requirements: 12V DC Outer Tube Diameter: 2 1/5” Power Cord Length: 6’,#12 gauge UL Wire Foot Pad Diameter:6” LED Work Lights For Easy Nighttime Hookups Shipping Weight: 23.15lbs About jacks CONTENTS OF KIT: Removable Foot Pad 3/8” Safety Lock Pin Manual Crank Handle Three 3/8” Star Washers TOOLS REQUIRED: 9/16” Wrench Torque Wrench Wire Cutters Wire Strippers Crimpers or Soldering Iron Disconnect the jack from the power source. Remove the rubber access cover on the top of the jack. Insert the manual crank handle into the access hole on the top of the jack, engaging the drive screw. Rotate the manual crank handle counter-clockwise to extend the jack, and clockwise to retract it. Remove manual crank handle and replace manual override plug. Your trailer's TW should be around 10 percent to 15 percent of your gross trailer weight (GTW), which is the weight of your trailer when it's fully loaded. Durable and Sturdy: Heavy-gauge steel construction ensures durability and strength; Black powder coat finish resists rust and corrosion; Durable, textured-housing prevents chips and cracks. Weize electric jack lets you raise and lower your A-frame trailer quickly and easily. 3,500 lbs. 2-1/4, inner tube dia.: 2. To ensure great performance even at night, this jack also comes with a front-facing LED light . The unit also comes with a manual crank handle in case you lose power. Warranty: Meets international quality standards. don't hesitate to call us if you have any questions, our support team is on standby for YOU.
