CNCTOPBAOS Upgrade 3018-PRO CNC Router Kit,with GRBL Offline Controller,with 3 Axis Limit Switches,Emergency Stop,DIY Mini Desktop Cutting Wood Acrylic PVC PCB Engraving Milling Machine

Upgraded CNC 3018-PRO DIY Mini CNC Router Kit engraving machine Package include: 1Set Upgraded 3 Axis 3018-PRO CNC Router Engraving Milling Machine Kit 1x GRBL Offline Controller 1x 775 spindle motor with ER11 Collet 3.175mm 1x 24V DC 5A Power Supply 10 x Tip 0.1 mm, 20° φ3.175 mm Drill Bits 4x Plate clamps 3x Stepper motor harness 60cm Requires assembly Specification: Working area: 300x180x45mm ( 11.8 x 7.1 x 1.8) Frame size: 420x350x270mm ( 16.53 x13.78 x 10.63) Spindle: 775 100W spindle motor (24V:10000r/min) Processing thickness: 4.5cm (1.8) (height 6.4cm) Material: PA6 nylon & aluminum profile Screw rod: T8 screw rod, lead 4mm, double copper nut to eliminate backlash Spindle Chuck: ER11 Collet (can be equipped with 0-7mm) Step motor: Nema17 stepper motor 34MM,1.33A,0.3N.m,43oz-in Power supply : 24V 5.6A power adapter (input voltage 110-240VAC) 775 spindle motor Parameters of this 775 spindle : 100W spindle motor (12-36V) 24V:10000rpm/min Mounting hole diameter: M4 screw hole; Mounting hole pitch: about 29mm. Spindle PWM speed: Support;power 0-100% adjustable Shaft diameter: 15mm; GRBL controller board Connection: USB (USB-CH340) Spindle drive chip: MOSFET (recommendation 24V, current : within 10A Spindle PWM speed: Support Support stepper motor: 12V, maximum current of 2A or less is recommended within 1.5A and additional heat. Support oftware: GRBL controller,Candle, UniversalGcodeSender Input voltage: 12-24VDC The spindle supports 0-100% adjustable PWM power. Support PWM / TTL signal control, power 0-100% adjustable! Increase the power button switch Cancel the drive module,integrate the imported stepper motor drive,no need to worry about module damage. And integrated heat dissipation aluminum alloy. Add emergency stop ports & XYZ limit switches ports Add offline recognition function, you can insert offline module and computer at the same time. can support 20,000 rpm spindle. Add Offline controller Main Page Ctrl: Machine Control; File: Use the Gcode file; Press [Y+] [Y-] to select; Press[Ok] to Enter Control Page X± Y± Z±: Moving Axis Exit/Step: Change Step/Exit (long press) How to increase the spindle power: After pressing the spindle button, press and hold the OK button and the Z+ button simultaneously to increase the speed. How to decrease the spindle: After pressing the spindle button, press and hold the OK button and the Z- button simultaneously to decrease the speed. Press [Y+] [Y-] to select file Press [Ok] to Enter Note:Long press [Exit] to stop machining Add the power button switch and move the power switch button from the bottom to the side,simple operation,more safety in the process of using the machine. Advantage Add emergency stop button port, probe port and XYZ limit port. Add the outer casing: protect control board in transit,to avoid short circuit problem during use; Add the power button switch; Cancel the drive module,use integrated imported stepper motor drive,with short circuit protection,and integrated heat dissipation aluminum alloy; Add the fan port to force heat dissipation; Add offline recognition,can insert offline modules and computers at the same time. Enhanced spindle drive,can support 20000rpm spindle. Support two engraving methods The control board support two engraving methods,our package comes with a spindle motor but without the module in the picture above. Q&A Q: What materials can the milling cutter generally engrave or cut? A: Wood, acrylic (acrylic), pcb, pvb, soft metal, iron, glass, stone etc. Q: What thickness of wood or acrylic can generally be cut by module? A: 3-5mm wood board (acrylic), speed setting 100, power setting 1000; Multiple cuts can cut 12mm wooden boards by spindle. Applications&Software Applications CNC 3018-PRO Mini CNC machine small size, light weight, USB interface, GRBL control systems, great cnc router machine for beginers; Main application:can be engraved plastic, wood, acrylic, pvc, pcb, wood and the like material. If you change the spindle to a module,then also can carve the kraft paper, wood, leather(wallet), bamboo, rubber. Q:What should I do if the control board cannot be connected? A:Exit the software, unplug the wire, and reconnect it. Q: How to modify the parameters when the limit switch is activated? A: Enter 21=1 and 22=1 commands. Q: The engraved image is reversed,what should I do? A: Enter 3=2 or RST=*command Software used to create Gcode: Carbide Create, Artcam, MeshCam, Fusion360, Inkscape etc. Type: Upgraded CNC 3018-PRO with Offline Controller; We have added E-Stop button and XYZ limit switches; The two sides of the Y-axis have been replaced by orange electric wood resin boards,the sturdy outer frame is made of resin,the workbench is made of aluminum alloy,and the screw material is made of stainless steel,making the machine more lightweight,delicate and durable,and is highly favored by CNC beginners and enthusiasts With offline controller: You can operate this machine without connect to the computer; offline controller included a SD card reader to write into the root directory G-code files or NC file; Support manually adjust X, Y, Z axis location as engraving starting point,manually open or close spindle m,43 oz-in; Computer System Requirements:Windows XP SP3,Win 7,Win 8,Win 10,Win 11 32/64 can be and Linux Instructions: Our parcel include a 4G USB flash drive,it include the detailed installation instructions,user manual and GRBL software; We also have detailed assembly and usage video tutorials, as well as strong after-sales technical support, so you don't have to worry about the assembly and use of the machine at all Specifications of GRBL Control Board: Added the outer casing,emergency stop button port,tool setting/probe port,X/Y/Z axis limit port and add the power button switch,with the fan to force heat dissipation,enhanced spindle drive,can support max 20000rpm spindle,and also can support 0.5W-20W 12V PWM/TTL engraver module Advantages of Upgraded Version: The machine has added an E-stop button;During the carving process,if there is an emergency situation,the user can press the button to stop the operation; Added limit switches for X/Y/Z axis,when the machine moves up and down or left and right, if it exceeds the travel range, it will trigger a stop,making the operation safer and more reliable
