Heavy Duty 8 Linear Actuator 8 Inch Stroke 12 Volt DC 330 Pound Max Lift LBS

A heavy duty actuator with a stroke length of 8. The maximum load (push or pull) is 330 lbs (1500N). This unit has built-in limits switches to cut power automatically at the end of travel. This can be used in harsh environments as it is IP54 rated (weather resistant). This actuator has a position feedback mechanism based on pulses from a hall effect switch. When read by a microcontroller, each pulse represents 0.007046 inches (0.17896mm) or travel. The mounting brackets and pin are included. When positive supply voltage is connect to the Red and Black leads, the actuator will extend. To use the hall position sensor, connect Green to ground, White to supply (5v), and Yellow to a 10k pull-up resistor. VERSATILE: 12v or 24v operation EXTRAS: Position feedback, Mounting brackets, Weather resistant, Limit switches
